Installing Red Hat 7 Setp By Step

After six-plus months of public beta testing and more than three years after its previous major point release, RHEL (Red Hat Enterprise Linux) version 7 is out. The update speaks to Red Hat's interests in outfitting RHEL with many of the latest enterprise and data center features. Here are the five top-of-the-line new additions to RHEL 7 that caught our eyes.

Here are the step by step screenshot for the installation of Red Hat Enterprise Linux 7 .

Once you insert and boot your machine with the RHEL DVD, you will get the below screen. Select "Install Red Hat Enterprise Linux 7.0" and Press "Enter".

As you see the installation process is initiated

Select the Language preference

The Next screen contains almost all the configuration which has to be performed for the installation. Since we have already selected our Language and Keyboard preferences, we can skip that step here.

Lets start by setting the Date and Time

Select your Location as for me it is Asia/Kolkatta

Next we will select the packages which we want to install. So Select "Software Installation" which will lead you to the below screen. In my case I will install the "Base Installation" package having "Server with GUI" and in case you want to add any extra Add On, you can select the same from the left panel as shown below.

Next we need to configure partitions. So select "Installation Destination"

Select the hard disk which you have used to install RHEL 7, as for my case as you can see 20GB hard drive.

Also if you want the OS to automatically create the partition select the same or else for this article lets manually create the partitions

You can create a partition with the below list of partition types. As for this article we will select LVM

Click on the "+" sign to add new partition.

For this article I will create /boot, /, swap partition under LVM with Volume Group name as "VolGroup00"

Change the partition type to Ext4 as by default XFS will be selected for every partition you create.

Once you change these settings make sure you "update settings"

By default Volume Group name is "rhel". Let us change it to "VolGroup00"

You can also configure the storage for RAID but let us skip that part as of now.

As you see all the mount points as planned are created with below name under LVM

VolGroup00-root

VolGroup-swap

Click on Done and select Accept Changes.

The last one is to Configure Network

Provide a hostname for your machine and enable the ethernet device. Next select Configure to configure network settings for your machine

Change the Ethernet device name or else you can skip that part. Next configure you IP details as per your environment i.e IPv4 or IPv6. We are using IPv4 so selected the "IPv4 Settings" and added the IP, Netmask,Gateway and DNS details in the same.. Click on "Done" to save the configuration and go a step back.

So we are done here with all the options on this screen. Next we can "Begin Installation"

As you see the installation has begun in the mean time you can add a password for your root user. Also you can create additional user by using the "User Creation" thumbnail.
